ASP.NET Core compatible dependency injection container in 200 lines of code.

9 minute read

While working on ASP.NET Core dependency injection implementation I’ve decided to write my own implementation to find out details of specification requirements, surprisingly it came out quite small and simple. In this article I’ll describe how to write one step by step.

Setup

To start we would need two projects - one for the container implementation and one for the tests. Implementation project would target as low as netstandard1.1 as it has all the things we need, and reference a single dependency Microsoft.Extensions.DependencyInjection.Abstractions which is set of abstraction for ASP.NET Core compatible dependency injection containers.

{
  "version": "1.0.0-*",
  "dependencies": {
    "Microsoft.Extensions.DependencyInjection.Abstractions": "1.0.0-*",
  },
  "frameworks": {
    "netstandard1.1": {
      "dependencies": {
        "System.Reflection": "4.1.0",
        "System.Collections": "4.0.11-*"
      }
    }
  }
}

We’ll need a source file that will contain a stub implementation:

using System;

namespace SimpleDI
{
    public class ServiceProvider : IServiceProvider
    {
        public object GetService(Type serviceType)
        {
            throw new NotImplementedException();
        }
    }
}

For the testing purposes lets create a typical dotnet cli test project and reference Microsoft.Extensions.DependencyInjection.Specification.Tests which contains a set of unit test which our implementation would be required to pass.

{
  "version": "1.0.0-*",
  "dependencies": {
    "dotnet-test-xunit": "2.2.0-*",
    "SimpleDI": "1.0.0-*",
    "Microsoft.Extensions.DependencyInjection.Specification.Tests": "1.0.0-*",
    "xunit": "2.2.0-*"
  },
  "frameworks": {
    "netcoreapp1.0": {
      "dependencies": {
        "Microsoft.NETCore.App": {
          "version": "1.0.0-*",
          "type": "platform"
        }
      }
    },
    "net451": {}
  },
  "testRunner": "xunit"
}

And in the last step lets add a stub test class, inheriting DependencyInjectionSpecificationTests and overriding container creation delegate. This will allow us to run specification tests against our implementation.

using System;
using Microsoft.Extensions.DependencyInjection;
using Microsoft.Extensions.DependencyInjection.Specification;

namespace SimpleDI.Tests
{
    public class SimpleDISpecificationTests : DependencyInjectionSpecificationTests
    {
        protected override IServiceProvider CreateServiceProvider(IServiceCollection collection) =>
            new ServiceProvider();
    }
}

Run dotnet test.

Commit on Github

Passed: 0/45

Trivial case

You’ll notice that the container creation delegate receives IServiceCollection interface instance, which by itself is IList<ServiceDescriptor>. The ServiceDescriptor class contains information about a registered service:

ImplementationFactory - if instance of a service is created using factory this property would contain the factory delegate.
ImplementationInstance - if a service is represented by a know instance this property will contain it.
ImplementationType - if instance of a service is created by constructing a type this property would contain the type reference.
ServiceType - a type reference of a service being registered.
Lifetime - we’ll discuss later.

So to implement a trivial case we would need to store the descriptor list and use it to return an instance from GetService method:

using System;
using System.Collections.Generic;
using System.Linq;
using Microsoft.Extensions.DependencyInjection;

namespace SimpleDI
{
    public class ServiceProvider : IServiceProvider
    {
        private readonly ServiceDescriptor[] _services;

        public ServiceProvider(IEnumerable<ServiceDescriptor> services)
        {
            _services = services.ToArray();
        }

        public object GetService(Type serviceType)
        {
            var descriptor = _services.FirstOrDefault(service => service.ServiceType == serviceType);
            if (descriptor == null)
            {
                return null;
            }

            if (descriptor.ImplementationInstance != null)
            {
                return descriptor.ImplementationInstance;
            }
            else if (descriptor.ImplementationFactory != null)
            {
                return descriptor.ImplementationFactory(this);
            }
            else if (descriptor.ImplementationType != null)
            {
                return Activator.CreateInstance(descriptor.ImplementationType);
            }
            // we should never get here
            throw new NotImplementedException();
        }
    }
}

Calling services.ToArray(); in constructor is required to protect from outside changes of the service collection which should not affect already created instances.

Test class needs to be changed to pass IServiceCollection to ServiceProvider constructor:

using System;
using Microsoft.Extensions.DependencyInjection;
using Microsoft.Extensions.DependencyInjection.Specification;

namespace SimpleDI.Tests
{
    public class SimpleDISpecificationTests : DependencyInjectionSpecificationTests
    {
        protected override IServiceProvider CreateServiceProvider(IServiceCollection collection) =>
            new ServiceProvider(collection);
    }
}

After running dotnet test you’ll see that even this implementation passes quite a bit of tests.

Commit on Github

Passed: 18/45

Constructor

Many of the tests fail with No parameterless constructor defined for this object. on Activator.CreateInstance line because a service implementation type has constructor with parametes and constructor injection is a required feature. Specification requires us to use constructor with most parameters if all of them can be satisfied.

private object CreateInstance(Type implementationType)
{
    var constructors = implementationType.GetTypeInfo().
        DeclaredConstructors.OrderByDescending(c => c.GetParameters().Length);

    foreach (var constructorInfo in constructors)
    {
        var parameters = constructorInfo.GetParameters();
        var arguments = new List<object>();

        foreach (var parameterInfo in parameters)
        {
            var value = GetService(parameterInfo.ParameterType);
            // Could not resolve parameter
            if (value == null)
            {
                break;
            }
            arguments.Add(value);
        }

        if (parameters.Length != arguments.Count)
        {
            continue;
        }
        // We got values for all paramters
        return Activator.CreateInstance(implementationType, arguments.ToArray());
    }
    throw new InvalidOperationException("Cannot find constructor");
}

And replace Activator.CreateInstance call with CreateInstance call in GetService.

Commit on Github

Passed: 24/45

Lifetime

There are three kinds of service lifetimes in ASP.NET Core:

Transient - new instance is created per service resolution request.
Singleton - single instance is created and cached for whole container hierarchy.
Scoped - instance is cached in IServiceProvider it was created in.

To describe a notion of scopes we need to look at IServiceScopeFactory and IServiceScope interfaces:

public interface IServiceScopeFactory
{
    IServiceScope CreateScope();
}

public interface IServiceScope : IDisposable
{
    IServiceProvider ServiceProvider { get; }
}

Dependency injection container needs to be able to provide IServiceScopeFactory implementation which clients would use to create scopes. Service scope is just a service provider that guarantees that all services created using it would be disposed with scope being disposed.

After implementing lifetime support service provider class grew quite a bit:

public class ServiceProvider : IServiceProvider, IServiceScopeFactory, IDisposable
{
    private readonly Dictionary<Type, object> _scoped = new Dictionary<Type, object>();
    private readonly List<object> _transient = new List<object>();

    private readonly ServiceDescriptor[] _services;
    private readonly ServiceProvider _root;

    private bool _disposed;

    public ServiceProvider(IEnumerable<ServiceDescriptor> services)
    {
        _services = services.ToArray();
        _root = this;
    }

    public ServiceProvider(ServiceProvider parent)
    {
        _services = parent._services;
        _root = parent._root;
    }

    public object GetService(Type serviceType)
    {
        if (serviceType == typeof(IServiceScopeFactory))
        {
            return this;
        }

        var descriptor = _services.FirstOrDefault(service => service.ServiceType == serviceType);
        if (descriptor == null)
        {
            return null;
        }
        switch (descriptor.Lifetime)
        {
            case ServiceLifetime.Singleton:
                return Singleton(serviceType, () => Create(descriptor));
            case ServiceLifetime.Scoped:
                return Scoped(serviceType, () => Create(descriptor));
            case ServiceLifetime.Transient:
                return Transient(Create(descriptor));
            default:
                throw new ArgumentOutOfRangeException();
        }
    }

    private object Transient(object o)
    {
        _transient.Add(o);
        return o;
    }

    private object Singleton(Type type, Func<object> factory)
    {
        return Scoped(type, factory, _root);
    }

    private object Scoped(Type type, Func<object> factory)
    {
        return Scoped(type, factory, this);
    }

    private static object Scoped(Type type, Func<object> factory, ServiceProvider provider)
    {
        object value;
        if (!provider._scoped.TryGetValue(type, out value))
        {
            value = factory();
            provider._scoped.Add(type, value);
        }
        return value;
    }

    private object Create(ServiceDescriptor descriptor)
    {
        if (descriptor.ImplementationInstance != null)
        {
            return descriptor.ImplementationInstance;
        }
        else if (descriptor.ImplementationFactory != null)
        {
            return descriptor.ImplementationFactory(this);
        }
        else if (descriptor.ImplementationType != null)
        {
            return CreateInstance(descriptor.ImplementationType);
        }
        // we should never get here
        throw new NotImplementedException();
    }

    public void Dispose()
    {
        if (!_disposed)
        {
            _disposed = true;
            foreach (var o in _transient.Concat(_scoped.Values))
            {
                (o as IDisposable)?.Dispose();
            }
        }
    }

    public IServiceScope CreateScope()
    {
        return new ServiceScope(new ServiceProvider(this));
    }

    private object CreateInstance(Type implementationType)
    {
        var constructors = implementationType.GetTypeInfo().
            DeclaredConstructors.OrderByDescending(c => c.GetParameters().Length);

        foreach (var constructorInfo in constructors)
        {
            var parameters = constructorInfo.GetParameters();
            var arguments = new List<object>();

            foreach (var parameterInfo in parameters)
            {
                var value = GetService(parameterInfo.ParameterType);
                // Could not resolve parameter
                if (value == null)
                {
                    break;
                }
                arguments.Add(value);
            }

            if (parameters.Length != arguments.Count)
            {
                continue;
            }
            // We got values for all paramters
            return Activator.CreateInstance(implementationType, arguments.ToArray());
        }
        throw new InvalidOperationException("Cannot find constructor");
    }
}

Three field were added: _scoped to cache scoped services, _transient to keep track of objects that were created by container and need to be disposed later and _root to keep track of root container used to cache singleton services.

Singleton lifetime is implemented as scoped always using _root as a scope. Also IServiceScopeFactory interface was implemented to return a new instances of ServiceScope class containig new ServiceProvider object that inherits list of services from current but has it’s own cache of scoped services.

internal class ServiceScope : IServiceScope
{
    private ServiceProvider _serviceProvider;

    public ServiceScope(ServiceProvider serviceProvider)
    {
        _serviceProvider = serviceProvider;
    }

    public IServiceProvider ServiceProvider => _serviceProvider;

    public void Dispose()
    {
        _serviceProvider.Dispose();
    }
}

The `ServiceProvider.Dispose` method disposes all objects owned by service provider and has reentrancy check in case a service injecting `IServiceProvider` would decide to dispose it causing an infinite recursion.

[Commit on Github](https://github.com/pakrym/di200loc/commit/3da8c1387be92c303b9195f46442dd47ea7090d2)

Passed: 36/45

Open generics

ASP.NET Core requires a feature called “open generics” to be supported by service providers, this means that if a services is registered as IService<> with implementation type Service<> a request for IService<Foo> would return Service<Foo> instance.

public object GetService(Type serviceType)
{
    if (serviceType == typeof(IServiceScopeFactory))
    {
        return this;
    }

    var descriptor = _services.FirstOrDefault(service => service.ServiceType == serviceType);
    if (descriptor == null)
    {
        if (serviceType.IsConstructedGenericType)
        {
            var genericType = serviceType.GetGenericTypeDefinition();
            descriptor = _services.FirstOrDefault(service => service.ServiceType == genericType);
            if (descriptor != null)
            {
                return Resolve(descriptor, serviceType, serviceType.GenericTypeArguments);
            }
        }
        return null;
    }
    return Resolve(descriptor, serviceType, null);
}

private object CreateInstance(Type implementationType, Type[] typeArguments)
{
    if (typeArguments != null)
    {
        implementationType = implementationType.MakeGenericType(typeArguments);
    }
    var constructors = implementationType.GetTypeInfo()
        .DeclaredConstructors.OrderByDescending(c => c.GetParameters().Length);
    foreach (var constructorInfo in constructors)
    {
        var parameters = constructorInfo.GetParameters();
        var arguments = new List<object>();

        foreach (var parameterInfo in parameters)
        {
            var value = GetService(parameterInfo.ParameterType);
            // Could not resolve parameter
            if (value == null)
            {
                break;
            }
            arguments.Add(value);
        }

        if (parameters.Length != arguments.Count)
        {
            continue;
        }
        // We got values for all paramters
        return Activator.CreateInstance(implementationType, arguments.ToArray());
    }
    throw new InvalidOperationException("Cannot find constructor");
}

Code was added to deconstruct generic type and check if there is service registered with closed generic type ISerivce<> if it’s found we construct an instance taking in account requested generic type arguments.

Commit on Github

Passed: 37/45

Open IEnumerable

When IEnumberable<T> is requested provider should return enumeration containing resolved instances for all registered services with type T or empy IEnumerable if there is no services of requested type.

To implement this feature lets change GetService method to this:

public object GetService(Type serviceType)
{
    if (serviceType == typeof(IServiceScopeFactory))
    {
        return this;
    }

    var descriptor = _services.FirstOrDefault(service => service.ServiceType == serviceType);
    if (descriptor == null)
    {
        if (serviceType.IsConstructedGenericType)
        {
            var genericType = serviceType.GetGenericTypeDefinition();
            if (genericType == typeof(IEnumerable<>))
            {
                var genericAgument = serviceType.GenericTypeArguments[0];
                var descriptors = _services.Where(service => service.ServiceType == genericAgument).ToList();
                var array = Array.CreateInstance(genericAgument, descriptors.Count());
                for (int i = 0; i < array.Length; i++)
                {
                    array.SetValue(Resolve(descriptors[i], descriptors[i].ServiceType, null), i);
                }
                return array;
            }

            descriptor = _services.FirstOrDefault(service => service.ServiceType == genericType);
            if (descriptor != null)
            {
                return Resolve(descriptor, serviceType, serviceType.GenericTypeArguments);
            }
        }
        return null;
    }
    return Resolve(descriptor, serviceType, null);
}

Commit on Github

Passed: 42/45

Final fixes

Two of the last three tests are failing because service provider should be able to return itself when IServiceProvider type is requested so fixing first if in GetService makes them pass:

if (serviceType == typeof(IServiceProvider) ||
    serviceType == typeof(IServiceScopeFactory))
{
    return this;
}

And the last failure is caused by selecting first ServiceDescriptor in line var descriptor = _services.FirstOrDefault(service => service.ServiceType == serviceType); instead on the last one as specification requires: services registered later override ones registered earlier. Thats an easy fix FirstOrDefault -> LastOrDefault.

Commit on Github

Passed: 45/45

Web application

It’s time to use our newly written service provider in actual web application. Let’s create Web Application project in Visual Studio and change ConfigureServices to return our service provider implementation.

public IServiceProvider ConfigureServices(IServiceCollection services)
{
    // Add framework services.
    services.AddApplicationInsightsTelemetry(Configuration);

    services.AddMvc();
    return new SimpleDI.ServiceProvider(services);
}

Start the application! If everything was done right you will see ASP.NET Core MVC application running and fully functional in your browser.

Commit on Github

Notes

My goal was to write a dependency injection implementation that passes ASP.NET Core tests and is simple to understand at the same time it’s far from being complete, bug-free, performant or reliable.

Some of the issues with this implementation:

Not thread safe
If multiple scoped services are requested as IEnumerable first of them would be cached and returned each time.
Instances of services would be created and discarded in constructor selection process.
Insane ammount of reflection and LINQ makes it very slow.

Pavel Krymets

Setup

Trivial case

Constructor

Lifetime

Open generics

Open IEnumerable

Final fixes

Web application

Notes
